Dual-Line Grinding and Polishing Machine
Classification:
Photovoltaic Processing Equipment
Key words:
Dual-Line Grinding and Polishing Machine
Product Details
Product Usage
The dual-line grinding and polishing machine is used for the process requirements of grinding and polishing the four sides and four edges of rectangular bars of monocrystalline silicon and polycrystalline silicon. It can also meet the control functions of rough grinding, precision grinding, chamfering, and rounding at the same time or separately.
Technical Parameters
|
Item |
Technical Specifications |
|
Grinding Length |
200～950mm |
|
Processing Margin |
150～230mm |
|
Chamfering |
C0.2～C15mm or ≥R5mm |
|
Number of Bars Processed |
2 |
|
Size Tolerance |
±0.05mm |
|
Flatness of Four Planes |
≤0.05mm |
|
Parallelism of Four Planes |
≤0.05mm |
|
Surface Roughness |
Ra≤0.2µm |
|
Power Supply |
Three-phase 380V 50Hz |
|
Power Consumption |
＜40kWh |
|
Total Weight |
Approximately 25T |
|
Dimensions (D × W × H) |
4.5m×3.9m×3m (excluding pedal) |
Technical Features:
1. The motor direct drive control technology is adopted to improve the rotational accuracy of the grinding wheel and the grinding efficiency. The efficiency is about 20% faster than the mainstream equipment in the market.
2. Automatic grinding feed is realized through servo motors, high-precision ball screws, and guide rails, ensuring batch processing accuracy within ±0.05mm.
3. The seamless connection is achieved through the double-line docking structure and the double-position chamfering machine, enabling an assembly line process of "opening-grinding-polishing-chamfering-unloading".
4. The standby port is set up at the inlet to prevent the machine from stopping due to material blockages, thereby further improving the production efficiency of the entire production line.
5. The modular structure design is adopted to realize the automatic combination of rough grinding and precision grinding, thereby improving equipment utilization.
6. The grinding wheel adopts an integrated module structure, which is easy to replace and reduces maintenance time.
7. The grinding wheel has an automatic repair function and can be automatically adjusted and repaired according to process requirements.
8. The positioning and centering mechanism is adopted to ensure the accuracy of the bar's position, ensuring that the grinding and polishing accuracy meets the standard.
9. The integrated frame structure is adopted to ensure the overall machining accuracy of the equipment.
10. The equipment is easy to operate and uses an intelligent formula management system, which can realize unmanned automatic production management.
11. A mimic chamfering grinding wheel structure can be equipped according to product needs, meeting different chamfering requirements.
12. The equipment requires a smaller area than conventional equipment, with a size of only (4.5m×3.9m×3m).
